Auto Molding Equipment

全自动塑封系统

Auto Molding Equipment


【Characteristic】

● Fully automatic plastic packaging system, also known as fully automatic packaging system;

● Servo control system, PLC (Omron)+controller;
● WIN10+15 inch touch screen+touch keyboard;
● CCD image detection, anti backtracking detection for incoming materials;
● Can correspond to a large lead frame of 90mmx300mm;
● Standardized mold structure for easy replacement;
● Equipped with a visual System identification to identify the feeding direction;
● Efficient cake feeding components, aluminum material box feeding;
● Automatic box entry, double material receiving box stacked material receiving;
● Supports flexible expansion of up to 4 sets of compressors, achieving high UPH;
● Optional mold vacuum pumping function, isolation mold function, and post molding detection function;
● Using imported raw materials, with stable performance, high accuracy, long service life, and guaranteed quality;
● Customized as needed.





【Performance Parameters】

● Closing pressure: 98-1764kN;

● Injection pressure: 4.9-29.4kN adjustable;
● Applicable lead frame/substrate size: width 20-90mm, length 124-300mm, thickness 0.15-1.2mm;
● Applicable size of plastic sealing material: diameter φ   11-20mm, length/diameter 1.2-2.0 (Max 35mm).


Equipment Details

全自动塑封系统全自动塑封系统


Sample Display

全自动塑封系统制造样品
